Tests

SATS member laboratories carry out type tests and development tests

  • Tests are carried out in accordance with international and regional standards such as for example IEC, ANSI/IEEE and CENELEC, as well as national standards and client's requirements.
  • When testing according to international standards for certification purposes, all relevant STL Guides and procedures are strictly adhered to.
  • All tests are witnessed by inspectors assigned by SATS Certification and the test reports are counter-signed by the inspector in charge.





Switching capability

SATS offers a full range of switching tests and test facilites can be tailored to the client's need in terms of power, voltage and breaking requirements.

HV direct test

  • 3-phase 4000 MVA short-circuit power
  • 250 kV, 280 kA peak current, 16 - 60 Hz

MV direct test

  • 3-phase: 250 MVA, 3.6 - 38 kV
  • 105 kA peak current, 40 kArms 50 Hz

LV direct test

  • 250 MVA, 250 - 1000 V
  • 100 kA (1 sec), 50 Hz

Synthetic tests

  • Two circuits, 4-parameter TRV, 3.2 MJ
  • ±660 kV/AC recovery voltage, 550 kV full-pole tests

Dielectric

SATS member labs offer a wide range of dielectric testing facilities, both for circuit breakers and cables.

Test capabilities include

  • AC voltage: Up to 1050 kV, 1.5 A, 50 Hz
  • Series resonance test systems: 1600 kV, 6.5 A; 600 kV, 60 A; 220 kV, 400 A
  • Lightning impulse voltage: 3600 kV, 450 kJ
  • Switching impulse voltage: 2300 kV
  • DC voltage: 2100 kV, 10 mA; 1200 kV, 300 mA
  • Partial discharge: According to IEC 60270 and several other methods
  • Radio Interference Voltage (RIV): According to IEC and ANSI/IEEE standards

Environmental

In SATS laboratories, hot and cold climates can be simulated and equipment tested either energized or de-energized. Various environmental stress factors, such as UV radiation, salt deposits, ice etc. can also be added.

Tests can be carried out according to IEC 60694, 61299, 60137 and the 62271 series of standards, as well as client's requirements.

  • Temperature range -55 oC to + 70 oC
  • Humidity Up to 90% RH at + 40 oC
  • Cylindrical test hall: Ø 18 m, h 23 m; -10 to +40 oC
  • Climate chambers: 3 x 3 x 5 m ; -55 oC to +70 oC
  • Voltage feeds: Up to 1050 kV AC; 1200 kV DC

Mechanical

A wide range of mechanical tests can be carried out in SATS laboratories, including:

  • Mechanical endurance
  • Tensile/tensile bending tests
  • Cantilever tests
  • Full-scale dynamic flex-testing
  • Pressure tests
  • Crush testing
  • Corrosion testing
  • Verification of degree of protection
  • Interlock testing
  • Tightness/leakage rate testing

Making and breaking

  • Short-circuit current making and breaking
  • Terminal faults
  • Short-line fault
  • Out-of-phase
  • Line-charging current
  • Cable-charging current
  • Capacitor bank current
  • Back-to-back capacitor
  • Shunt reactor switching

Current-carrying capacity

  • Short-time current tests up to 150 kA (1 sec) three-phase and single phase
  • Peak current up to 350 kA



Temperature rise tests

  • Single-phase/three-phase up to 25 kA / 25 kA
  • Temperature measurements
  • Voltage-drop measurement / Measurement of the resistance of the circuit



Arc fault

Arc fault tests are carried out according to IEC and PEHLA specifications:

  • Single-phase and three-phase
  • 63 kA 1 sec; 170 kA peak current
